DG250E • DG250E

DG250E

DG250E

ชนิด :
16,17,18
ชื่อแบรนด์ :
DRYER GROUP
หมายเลขรุ่น :
DG250E

DG-250E Dryer Group

Features

  • Wall structure made of Stainless Steel 304 or Aluzinc, powder-coated for corrosion resistance; PU foam insulation available in 1" and 2" (optional)
  • Column and beam structure made of Aluminium, factory-formed; corner joints made of ABS for high durability and weight support (optional)
  • Desiccant wheel coated with silica gel, environmentally friendly; washable with water
  • Automatic shutdown when the desiccant wheel stops rotating
  • Humidity control via Digital Controller
  • High-efficiency air filters, removable and washable; filters can remove 60–70% or up to 95% of dust (optional)
  • High-performance Motor Gear drives the desiccant wheel efficiently

Technical Specifications

  • Dry Air Flow: 250 CMH
  • Dry Air Static Pressure: 200 Pa
  • Wet Air Flow: 125 CMH
  • Wet Air Static Pressure: 280 Pa
  • Dehumidification Capacity: 2 kg/h (at 20°C, 60% RH)
  • Heater Power Supply: 2 kW (220V/50Hz)
  • Total Power: 2.5 kW (220V/50Hz)
  • Electrical Requirement: 220V/50Hz/20A
  • Operating Temperature: 30–40°C
  • Max Noise Level (without ductwork): 65 dBA
  • Air Filter Efficiency: EU3–EU9
  • Insulation Thickness: 20 mm
  • Weight: 20 kg
  • Unit Dimensions (W × L × H): 400 × 400 × 400 mm
