DG250E
DG250E
ชนิด :
16,17,18
ชื่อแบรนด์ :
DRYER GROUP
หมายเลขรุ่น :
DG250E
DG-250E Dryer Group
Features
- Wall structure made of Stainless Steel 304 or Aluzinc, powder-coated for corrosion resistance; PU foam insulation available in 1" and 2" (optional)
- Column and beam structure made of Aluminium, factory-formed; corner joints made of ABS for high durability and weight support (optional)
- Desiccant wheel coated with silica gel, environmentally friendly; washable with water
- Automatic shutdown when the desiccant wheel stops rotating
- Humidity control via Digital Controller
- High-efficiency air filters, removable and washable; filters can remove 60–70% or up to 95% of dust (optional)
- High-performance Motor Gear drives the desiccant wheel efficiently
Technical Specifications
- Dry Air Flow: 250 CMH
- Dry Air Static Pressure: 200 Pa
- Wet Air Flow: 125 CMH
- Wet Air Static Pressure: 280 Pa
- Dehumidification Capacity: 2 kg/h (at 20°C, 60% RH)
- Heater Power Supply: 2 kW (220V/50Hz)
- Total Power: 2.5 kW (220V/50Hz)
- Electrical Requirement: 220V/50Hz/20A
- Operating Temperature: 30–40°C
- Max Noise Level (without ductwork): 65 dBA
- Air Filter Efficiency: EU3–EU9
- Insulation Thickness: 20 mm
- Weight: 20 kg
- Unit Dimensions (W × L × H): 400 × 400 × 400 mm
